52 Ton Trane CGAM 052F Air-Cooled Chiller

Used Trane Air-Cooled Chiller, 52 Ton Cooling Capacity, 460/60/3 Rated Voltage/HZ/PH, Design Pressure 650 High 238 Low, Refrigerant Charge 410A

Model Number: CGAM 052F 2G03 AXD2 A1A1 A1DX XA1D 1A2X XXXX XBXA 3A1D XXXL XXX

Rated Voltage: 200V/60HZ/3PH

Min CKT Ampacity: 106

Max Fuse/ Breaker: 125

Volt Utilization: 414-506

CPRSR MTR 1A: 21 RLA, 158 LRA

CPRSR MTR 1B: 21 RLA, 158 LRA

Fixed Speed Fan Motors: 2 QTY.

CKT 3 Freeze Protection Heaters: 538 watts

RFGT Charge Numbr: 410A

Oil Charge: OIL00079

CKT 1 LBS: 32

CKT 1 GAL: 1.7

CKT 2 LBS: 32

CKT 2 GAL: 1.7

Design Pressure: High Side 650, Low Side 238.

Update

Mfg. June 2012 52 tons Shipped Aug. 2012 from Colorado factory. Installed late September 21, 2012 Hours were not recorded during services. Temp sensor was replaced..no other faults.., a scroll chiller so blno oil sample analysis performed.
