800 HP Cleaver Brooks 250 PSI Steam Boiler 1993 Model CB-400-800

Used Cleaver Brooks Steam Boiler,Approx. 27,600 steam lbs/hr, 33,500,000 BTU/hr, Model CB 400-800, 800 HP, MAWP 250 PSI, Fuel Natural Gas, Serial No S-87359, Boiler Weight approx. 80,000 lbs, Built 1993

Cleaver Brooks 800 HP 250 PSI High Pressure Steam Boiler

Equipment Description

Manufacturer: Cleaver Brooks

Model: CB 400-800

Boiler Horsepower: 800 HP

Boiler Type: Steam Boiler

Fuel Type: Gas/Oil

Design Pressure or Maximum Allowable Working Pressure: 250 PSI

Heating Capacity: 33,500,000 BTU/hr

Steam Capacity: 27,600 steam Lbs/hr

Year Built: 1993

Serial No: S-87359

GPH Oil: 223.2

Electrical Requirements

Main Power Supply

Voltage: 600V

Phase: 3 PH

Hertz: 60Hz

Ampacity: N/A

Minimum Circuit Ampacity: 94.5 AMP

Maximum Rating of Circuit Protection: 5.6 AMP

Blower Motor

Horsepower: 50 HP

Air Compressor Motor

Horsepower: 7.5 HP

Oil Heater: 7.5 KW

Control Circuit

Volts: 120V

Phase: 1 PH

Hertz: 60 HZ

Ampacity: 7 AMP

Oil Pump Motor

Volts: 575V

Phase: 1 PH

Hertz: 60Hz

Ampacity: N/A

Overall Dimensions

Length: 26.58 ft

Width: 10.25 ft

Height: 10.5 ft

Boiler Weight: 80,000 lbs
