700 HP Cleaver Brooks 150 PSI Steam Boiler 1992 Model CB-700-700

Used Cleaver Brooks Steam Boiler, Approx. 24,150 steam lbs/hr, 29,291,000 BTU/hr. Model CB 700-700, 700 HP, MAWP 150 PSI. Fuel Natural Gas Fired, Boiler Weight 54,100 lbs. Built 1992

Cleaver Brooks 700 HP 150 PSI High Pressure Steam Boiler

Equipment Description

Manufacturer: Cleaver Brooks

Model: CB 700-700

Boiler Horsepower: 700 HP

Boiler Type: Steam Boiler

Fuel Type: Natural Gas

Design Pressure or Maximum Allowable Working Pressure: 150 PSI

Heating Capacity: 29,291,000 BTU/hr

Steam Capacity: 24,150 steam Lbs/hr

Year Built: 1992

Serial No: L-50522

GPH Oil: N/A

Electrical Requirements

Main Power Supply

Voltage: 460V

Phase: 3 PH

Hertz: 60Hz

Ampacity: 41.5 AMP

Minimum Circuit Ampacity: 51.5 AMP

Maximum Rating of Circuit Protection: 146 AMP

Blower Motor

Horsepower: 30 HP

Air Compressor Motor

Horsepower: N/A

Oil Heater: N/A

Control Circuit

Volts: 120V

Phase: 1 PH

Hertz: 60 HZ

Ampacity: 7 AMP

Oil Pump Motor

Volts: 460V

Phase: 1 PH

Hertz: 60Hz

Ampacity: 1.5 AMP

Overall Dimensions

Length: 26.41 ft

Width: 10.25 ft

Height: 10.5 ft

Boiler Weight: 54,100 lbs
